INNOVA 24V Mega Heat with Wall Mounted AHU

Indoor Air Flow (H/M/L) (CFM)

618/576/529

Indoor Noise Level (H/M/L) (dBA)

48/45/43

Net/Gross Weight (LBS)

88/109

Share

BI-COMM technology enables the INNOVA Inverter Heat Pump System to work with the INNOVA communicating wall control or to be compatible with existing 24V thermostats or smart/learning. As a result, the INNOVA System can be installed as a complete set or added in components to existing HVAC systems, without changing current duct design, refrigerant lines or communication wires.

Electrical Specification

Power Supply

208/230V,1Ph，60Hz

Outdoor/Indoor MCA

16/4.5

Connection Wiring

AWG 14-2

Outdoor/Indoor MOCP

20/15

Compressor RLA

10

Outdoor Fan Motor RLA

1

Outdoor Fan Motor W

80

Indoor Fan Motor RLA

3.5

Indoor Fan Motor W

N/A

Piping

Liquid Size

3/8in (9.52mm)

Gas Size

3/4 in(19mm) ODU Adaptor from 5/8 to 3/4

Drain Size

5/8in (15.88mm)

Max. Piping Length

98.4ft (30m)

Max. Height Difference

65.6ft (20m)

Max. Pre-charged Length

25ft (7.5m)

Refrigerant Pre-charged Amount

81.13oz (2300g)

Additional Charge of Refrigerant

0.69oz/ft (65g/m)

Connection Method

Flared
